AZPECTS.CO.UK Strong quick & easy to install Up to 80% cheaper than paving Strong, quick and easy to install, ground interlocking reinforcement grid EASYGrid
EASYGrid Ideal for shed bases, driveways, car spaces, equine turnout and so much more! KEY BENEFITS: Strong, lightweight & easy to install Supports up to 397 tonnes per m2 filled with aggregate Suitable for any areas needing ground or grass protection Easy interlocking connection Soil erosion prevention Eco-friendly Slip resistant, crack proof, frost & UV resistant Low maintenance Choice of infill materials including decorative aggregates & grass Permanent & temporary use Manufactured in the UK
GROUND REINFORCEMENT GRID IDEAL FOR: Residential Parking Construction Sites Private Roads Driveways Tow Paths Aircraft Parking Cycle Paths Helipads Green Roofing Golf Course Paths Wheelchair Access Routes Footpaths & Walkways Farms & Agricultural Areas Festival Sites & Showgrounds Emergency Vehicle Access Routes Car Parks - Permanent & Temporary Grass-seeded Areas & Green Spaces Hardstandings for Sheds, Outbuildings & Caravans Grass Parking Areas Campsites Playgrounds Outdoor Attractions Stables,Paddocks & Riding Arenas Embankment Stabilisation And much more... EACH 1M OF EASYGrid IS MADE UP FROM NINE 33CM SQUARES SUPPORTS UP TO 397 TONNES PER M2 FILLED WITH AGGREGATE
EASYGrid PRODUCT SPECIFICATION: Module Size 33.3cm x 33.3cm Module Depth 40mm Wall Thickness 3.2mm min. Module Weight 50g Modules/m2 9 M2/Pallet 50 Cell Size 7cm x 7cm Axle Weight 14 tonnes Load Bearing Up to 397 tonnes/m2 filled with aggregate Temperature Range -50OC to 65OC Chemical Resistance Sodium chloride, ammonia, acid rain & petroleum products Installation Times 120m2/man per hour (depending on ground conditions) Colours Black White Green
GROUND PREPARATION/INSTALLATION GUIDELINES BASE PREPARATION Following excavation of the existing ground, a geotextile layer should first be laid to create ground stability. To ensure optimum drainage, MOT Type 3 (graded crushed stone) should be used as the sub base layer. MOT Type 1 is not suitable. Assuming the existing ground is reasonably stable and free draining, a typical base for a car park would comprise of a compacted 150-200mm deep layer of Type 3. BEDDING (WHERE STONE/GRAVEL FINISH IS REQUIRED) A non-woven geotextile should be laid on top of the sub-base to act as a separating layer/ weed suppressant. This should then be topped with a 30mm depth of 4-10mm angular stone or grit sand with another layer of geotextile on top. The geotextile layer will stop the stone/grit from migrating down into the sub base and will also inhibit weed growth. BEDDING (WHERE GRASSED FINISH IS REQUIRED) An optional geotextile layer should be laid on top of the sub-base to act as a separating layer. This should be topped with a 30mm depth of 4-10mm grit sand with another layer of geotextile on top. LAYING Lay the pavers starting in the corner of the site. The lugs on the edge of the pavers should face the direction of installation. Offer the next panel in the same orientation so that the slots slide on to the lugs on the previous panel. Continue laying pavers in the desired direction, standing on the laid pavers when laying the next panel. Any excess can be cut with a hand saw. FILLING Stone/gravel fill - fill the pavers with free draining hard, angular stone nominal 10-14mm. Grass Fill - fill the pavers with clean friable topsoil or blended loam. Scrape away any overfill so that the top edges of all cells are visible. Grass seed can be applied to the finished surface or for the best results, mix together with the soil prior to filling. Suggested grass seed is a mix of 75% perennial rye and 25% creeping red fescue. Turf can also be rolled into pavers. Please note pavers should not be trafficked until grass is established.
EASYGrid Membrane MOT 3 Membrane Sub Soil
AZPECTS.CO.UK Azpects Ltd., Unit 13, Riverside Industrial Park, Rapier Street, Ipswich, IP2 8JX EASYGrid CAR SPACE SHED BASE DRIVEWAYS EQUINE TURNOUT
